G7/SIGC201 Silicone Glass Rod

Product Description:

Brand: YILONG

Materials: Silicone Resin + Glassfiber Cloth

Density: 1.8-2.0 g/cm³

Color: Reddish Brown

Thermal Resistance: ＞180℃

Thermal Class: C

Diameter: 6mm-200mm

Length: 1000mm

Packaging: Pallet, Wooden Box

Get A Quote

product details

Description

The G-7 Silicone Glass Rods are designed for high-performance in demanding environments. Made from a robust combination of glass fibers and silicone resin, they provide excellent electrical insulation, mechanical strength, and heat resistance. With a maximum operating temperature of 180°C, these rods maintain their structural integrity even under high-stress conditions, making them reliable for long-term industrial use.

Features

Outstanding electrical insulation performance under both dry and humid conditions
Exceptional thermal stability and high arc resistance for demanding environments
Self-extinguishing and flame retardant, meeting safety standards
High dielectric strength with minimal electrical losses at elevated temperatures
Composed of glass cloth reinforced silicone with natural cream-to-white coloration

Applications

Electrical insulation for transformers, switchgear, and other high-voltage equipment
Thermal and electrical insulation in heating elements, appliances, and industrial equipment
High-temperature electronic components where low dielectric loss is critical
Electrical systems operating under both humid and dry conditions
Applications requiring reliable insulation and flame-retardant performance in harsh environments

Technical Data Sheet

Test / Property	Unit	G-3	G-5/G9	G-7	G-10	G-11	G-11H
PHYSICAL
Density	g/cm³	1.8	1.85	1.8	1.8	1.8	1.9
Water Absorption, 24 hrs	%	2.65	0.6	0.1	0.1	0.2	0.2
MECHANICAL
Tensile Strength – lengthwise	MPa	289	425	138	310	296	280
Tensile Strength – crosswise	MPa	234	352	-	262	255	250
Flexural Strength – lengthwise	MPa	279	425	207	517	552	372
Flexural Strength – crosswise	MPa	234	352	-	448	483	124
Flexural Modulus – lengthwise	GPa	12.4	13.8	11	18.6	20.7	14
Flexural Modulus – crosswise	GPa	9.7	11.7	-	16.6	18.6	12
Izod Notched Impact – lengthwise	kJ/m²	0.64	0.67	0.64	0.71	0.61	16
Izod Notched Impact – crosswise	kJ/m²	0.59	0.45	-	0.61	0.46	14
Compressive Strength	MPa	379	448	345	448	434	346
Hardness, Rockwell M	—	110	115	105	110	112	112
THERMAL
Coefficient of Linear Thermal Expansion – lengthwise	10⁻⁶ / °C	1.46	1.27	1.15	0.88	1.15	15
Coefficient of Linear Thermal Expansion – crosswise	10⁻⁶ / °C	1.76	1.45	1.38	0.88	1.27	20
Max Operating Temperature	°C	180	140	220	140	165	180
Thermal Class	/	H	B	C	B	F	H
Flammability Rating	UL94	HB	V-0	V-0	HB	HB	HB
Thermal Conductivity	W/m·K	0.29	0.29	0.29	0.29	0.29	0.25
ELECTRICAL
Dielectric Strength (short time, 1/8" thick)	kV/mm	18.1	11.8	13.8	31.5	35.4	16
Dielectric Constant at 1 MHz	—	7.3	6.3	4.5	5	4.5	4.8
Dissipation Factor at 1 MHz	—	0.023	0.019	0.018	0.019	0.02	0.02
Arc Resistance	s	180	180	240	100	120	120
